Product Overview

Features

- Power range: 480W / 500W / 510W
- Vertex Series with N-Type polycrystalline cells
- Half-cell design for reduced power loss and better efficiency
- Optimized for commercial and utility-scale projects
- Durable construction with long service life
- High performance even in low-light conditions
- Pallet-packed for safe and efficient bulk delivery
- Eco-friendly and sustainable renewable energy solution

Specifications

- Brand: Trina Solar
- Series: Vertex N-Type
- Technology: Polycrystalline Half-Cell
- Power Output: 480W / 500W / 510W
- Module Efficiency: Up to 21% (approx.)
- Dimensions: 2094 × 1134 × 35 mm (approx.)
- Weight: 28–30 kg (approx.)
- Glass: Dual tempered glass with anti-reflective coating
- Frame Material: Anodized Aluminum Alloy
- Operating Temperature: -40°C to +85°C
- Maximum System Voltage: 1000V / 1500V DC
- Certifications: IEC 61215, IEC 61730, CE, TUV
- Warranty: 12 Years Product, 25 Years Linear Performance
