Mini Polycrystalline Solar Panels 12V 100W-200W Small Size PV Modules

The Mini Polycrystalline 12V Solar Panels (100W–200W) are compact, lightweight, and efficient PV modules designed for small-scale off-grid applications such as RV, boats, cabins, and tiny homes. With polycrystalline silicon cells, low LID, and durable construction, these panels provide reliable energy generation in a small footprint, making them ideal for portable and limited-space installations.

? Features

• Power range: 100W, 150W, 200W

• 12V output – ideal for small off-grid systems

• Mini and compact size – easy to install in limited spaces

• Polycrystalline silicon cells – reliable and cost-effective

• Suitable for RV, camper, boat, cabin, and small home solar systems

• Lightweight design for portable applications

• Low LID & PID resistance for stable long-term performance

• Weather-resistant with durable tempered glass and aluminum frame

? Specifications

• Power Output: 100W / 150W / 200W

• Module Efficiency: ~17% – 19%

• Cell Type: Polycrystalline Silicon

• Nominal Voltage: 12V DC

• Open Circuit Voltage (Voc): ~21V – 22.5V

• Short Circuit Current (Isc): ~5A – 9A

• Max System Voltage: 1000V DC

• Temperature Coefficient (Pmax): -0.45% / °C

• Operating Temperature: -40°C to +85°C

• Dimensions: ~1050 × 540 × 35 mm (100W) / varies for 150W & 200W

• Weight: ~8–12 kg

• Glass: 3.2mm AR-coated tempered glass

• Frame: Aluminum Alloy

• Junction Box: IP65, 2 Bypass Diodes
